560205

8619 – basic – panel 1/4 DIN – DC

Multi-channel

Remote Panel

12,00 V – 36,00 V

-10,00 °C – 70,00 °C

Categories: ,

Description

GENERAL INFORMATION
——————-
8619 – basic – panel 1/4 DIN – DC
Article number: 560205
Weight: 0.63 KG
Commodity Codes: 90268020

VOLTAGE / FREQUENCY
——————-
Voltage min / rated voltage: 12 V
Voltage max / rated voltage: 36 V
AC voltage: No
DC voltage: Yes

MATERIALS
———
Screws material: Stainless steel
Cover material: PC (polycarbonate)
Electronics body material category: Plastics
Electronics body material: PPO

PROCESS PRESSURE / TEMPERATURE
——————————
Temperature environment min: -10 °C
Temperature environment max: 70 °C

SEALING MATERIAL
—————-
Seal housing/cover material: Silicone

FEATURES
——–
Parametrization local: Yes
Parametrization separate: No
Parametrization fixed: No

PROPERTIES
———-
Type: 8619
Construction device: Remote Panel
Controller type: Multi-channel

ELECTRICAL PORT CONNECTION
————————–
Electrical connection 1 type: Screw terminal
Electrical connection plate material: Stainless steel

INPUT / OUTPUT
————–
Input type analog quantity: 0 PCE
Input type digital quantity: 2 PCE
Output type analog quantity: 2
Output 1 type analog current: 4-20 mA
Output 1 type analog voltage: without feedback
Output 2 type analog current: 4-20
Output type digital quantity: 2
Output 1 digital type: Transistor
Digital output 1 transistor contactless: 0,7 A
Output 1 digital transistor connection NPN: Yes
Output 1 digital transistor connection PNP: Yes
Output 2 digital type: Transistor
Output 2 digital transistor connection NPN: Yes
Output 2 digital transistor connection PNP: Yes
Digital output 2 transistor contactless: 0,7 A

SOFTWARE / COMMUNICATION
————————
Display type: Display

PROTECTION TYPE
—————
Protection type transmitter front/wall-installation NEMA: NEMA 4X
Protection type transmitter front/wall-installation (IP): IP65
Protection type transmitter back side (IP): IP20

LABEL
—–
Front foil material category: Elastomers
Front foil material: Silicone



Data Sheet: Click Here
